Custom 12V rocker switch with dual LED lights. 20A rated for easy, reliable power control in 4x4, marine, or RV setups.
$33.00
Trade$-33
GST Included
Free Shipping
Switch Function: On-Off
This item is a recurring or deferred purchase. By continuing, I agree to the cancellation policy and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted.
Product Info
This custom rocker switch gives you the freedom to choose your LED colour, function, symbol, and text, making it the most versatile 12V switch for any setup. Rated at 12v/20A, it often eliminates the need for relays, allowing simple installation while still handling heavy-duty loads. Available in blue, green, red, white, amber, or no LED, and with multiple functions including On-Off, On-Off-On, and momentary options, it’s perfect for lights, winches, and other accessories. With over 100 laser-etched symbols and unlimited text choices, you can give your 4x4, caravan, boat or camper a unique and professional touch. Built tough with IP66 protection, this switch delivers long-lasting reliability trusted by DIY users and installers alike.
Customisation
Simply select your preferred LED Colour, Function and Symbol from the respective drop down menus.
Click Here to view our full range of available symbols!
Type your desired text in the Text Box. Only text based letters, numbers, and characters can be processed from this section, which will create your final product.
Maximum 10 Characters per line
Maximum 2 lines - 20 Characters total
Special Notes:
Visual preview is for reference only. We will format the custom etching for best possible visual representation and to match our stocked Laser Etched units
Double check your spelling in the text box. This will be copied exactly
If you don't want any text etching, please write "NO TEXT" or leave the text box empty
The current formats shown for switch function are fixed and cannot be edited
We reserve the right to refuse etching of text containing inappropriate material or profanity
Please make your selection carefully as we cannot offer returns on our custom etched products
Specifications
• Common specifications
Common specifications for Custom Laser Etched Rocker Switch.
Specification
Value
Amps
10A, 20A
Input Voltage
12V, 24V
Depth
38mm
IP Rating
IP66
Package Contents
1 x Custom Laser Etched Rocker Switch
Maximum Rating
10A @ 24V, 20A @ 12V
Cutout Size
21.5mm (W) x 37.5mm (H)
LED Colour
Amber
• Variant specifications
Select all options above to see variant specifications
Specifications for selected variant of Custom Laser Etched Rocker Switch.
Specification
Amber / On-Off
Pins
5
Face size
24.5mm (W) x 49.5mm (H)
Throws
Single Throw
Poles
Single Pole
Switch function
On-Off
