19mm Aluminium (On)-Off Push Button Switch (T-A03 Series)

  • Sale
  • Regular price $15.00
GST included. FREE SHIPPING ON ALL ORDERS AUSTRALIA WIDE


Please select Colour from drop down menu

T-A03 Series Momentary (On)-Off Button/Switch

(On)-Off Momentary SPST switch - No LED illumination

Anodised Aluminium body

Push and Hold In for On, Release for Off

2 Pin solder terminals

Easy installation, 19mm panel mount

Lock nut, O-ring included

Includes:

  • 1 x 19mm Aluminium (On)-Off Push Button Switch
  • 1 x Lock Nut
  • 1 x O-Ring

Our 19mm Aluminium (On)-Off Push Button Switch range is an ideal component commonly used in a variety of applications, such as automotive, PC, PC simulation, or DIY projects.

The switch features a round, 15mm diameter button that can be pressed to activate or deactivate an electrical circuit. It has a sleek and durable aluminium body that is resistant to corrosion and wear. The switch is designed to be mounted through a 19mm hole (panel mount), and it can be secured using a locking nut that is included.

The switch operates as an (On)-Off type momentary type, which means that it has two states: On when the button is pressed, and Off when the button is released. It is rated for a maximum voltage and current of 12V DC/0.5A.

Maximum Rating: 0.5A@12v

Mounting Hole Diameter: 18.8mm-19mm (19mm panel mounting)

Button Size Diameter: 15mm

Face Size Diameter: 21.8mm

Terminals: 3mm (W) x 6.5mm (L)

Depth (from back of mounting face): 24mm

Simple 2 Pin installation

- Power In

- Power Out
